| A型扣压式胶管总成 |
B型扣压式胶管总成 |
| 产品代号：Q/JY303 |
产品代号：Q/JY304 |
 |
 |
| JBI885-77(JB/ZQ4427-86)A型 |
| 胶管内径mm |
公称通径mm |
工作压力(MPa) |
M |
扳手尺寸 |
| Ⅰ |
Ⅱ |
Ⅲ |
4SP |
| 4 |
4 |
20 |
- |
- |
- |
M12×1.25 |
14 |
| 6 |
6 |
20 |
25 |
40 |
100 |
M14×1.5 |
17 |
| 8 |
8 |
16 |
25 |
32 |
- |
M16×1.5 |
19 |
| 10 |
10 |
16 |
25 |
25 |
70 |
M18×1.5 |
22 |
| 13 |
10 |
13 |
20 |
25 |
60 |
M22×1.5 |
27 |
| 16 |
15 |
10 |
16 |
20 |
55 |
M27×1.5 |
32 |
| 19 |
20 |
10 |
16 |
20 |
46 |
M30×1.5 |
36 |
| 22 |
20 |
10 |
13 |
16 |
- |
M36×2 |
41 |
| 25 |
25 |
8 |
10 |
13 |
35 |
M39×2 |
46 |
| 32 |
32 |
7 |
10 |
10 |
32 |
M45×2 |
55 |
| 38 |
40 |
4 |
8 |
10 |
25 |
M52×2 |
60 |
| 45 |
40 |
- |
8 |
8 |
- |
M60×2 |
70 |
| 51 |
50 |
- |
7 |
8 |
20 |
M64×2 |
75 |
|
JBI886-77
(JB/ZQ4428-86)B型 |
| 胶管内径mm |
公称通径mm |
工作压力(MPa) |
D0 |
扳手尺寸 |
| Ⅰ |
Ⅱ |
Ⅲ |
4SP |
| 4 |
4 |
20 |
- |
- |
- |
4 |
6 |
| 6 |
6 |
20 |
25 |
40 |
100 |
6 |
8 |
| 8 |
8 |
16 |
25 |
32 |
- |
8 |
10 |
| 10 |
10 |
16 |
25 |
25 |
70 |
10/12 |
12 |
| 13 |
10 |
13 |
20 |
25 |
60 |
14 |
14 |
| 16 |
15 |
10 |
16 |
20 |
55 |
16 |
17 |
| 19 |
20 |
10 |
16 |
20 |
46 |
18 |
19 |
| 22 |
20 |
10 |
13 |
16 |
- |
22 |
24 |
| 25 |
25 |
8 |
10 |
13 |
35 |
28 |
30 |
| 32 |
32 |
7 |
10 |
10 |
32 |
34 |
36 |
| 38 |
40 |
4 |
8 |
10 |
25 |
42 |
46 |
|
| C型扣压式胶管总成 |
D型扣压式胶管总成 |
| 产品代号：Q/JY305 |
产品代号：Q/JY306 |
 |
 |
| JBI885-77C型 |
| 胶管内径mm |
公称通径mm |
工作压力(MPa) |
M |
扳手尺寸 |
| Ⅰ |
Ⅱ |
Ⅲ |
4SP |
| 4 |
4 |
20 |
- |
- |
- |
M12×1.25 |
14 |
| 6 |
6 |
20 |
25 |
40 |
100 |
M14×1.5 |
17 |
| 8 |
8 |
16 |
25 |
32 |
- |
M16×1.5 |
19 |
| 10 |
10 |
16 |
25 |
25 |
70 |
M18×1.5 |
22 |
| 13 |
10 |
13 |
20 |
25 |
60 |
M22×1.5 |
27 |
| 16 |
15 |
10 |
16 |
20 |
55 |
M27×1.5 |
32 |
| 19 |
20 |
10 |
16 |
20 |
46 |
M30×1.5 |
36 |
| 22 |
20 |
10 |
13 |
16 |
- |
M36×2 |
41 |
| 25 |
25 |
8 |
10 |
13 |
35 |
M39×2 |
46 |
| 32 |
32 |
7 |
10 |
10 |
32 |
M45×2 |
55 |
|
JBI886-77D型 |
| 胶管内径mm |
公称通径mm |
工作压力(MPa) |
D0 |
扳手尺寸 |
| Ⅰ |
Ⅱ |
Ⅲ |
4SP |
| 6 |
6 |
20 |
25 |
40 |
100 |
M14×1.5 |
17 |
| 8 |
8 |
16 |
25 |
32 |
- |
M16×1.5 |
19 |
| 10 |
10 |
16 |
25 |
25 |
70 |
M18×1.5 |
22 |
| 13 |
10 |
13 |
20 |
25 |
60 |
M22×1.5 |
27 |
| 16 |
15 |
10 |
16 |
20 |
55 |
M27×1.5 |
32 |
| 19 |
20 |
10 |
16 |
20 |
46 |
M30×1.5 |
36 |
| 22 |
20 |
10 |
13 |
16 |
- |
M36×2 |
41 |
| 25 |
25 |
8 |
10 |
13 |
35 |
M39×2 |
46 |
| 32 |
32 |
7 |
10 |
10 |
32 |
M45×2 |
55 |
| 38 |
40 |
4 |
8 |
10 |
25 |
M52×2 |
60 |
| 45 |
40 |
- |
8 |
8 |
- |
M60×2 |
70 |
| 51 |
50 |
- |
7 |
8 |
20 |
M64×2 |
75 |
|
| E型扣压式胶管总成 |
F型扣压式胶管总成 |
| 产品代号：Q/JY307 |
产品代号：Q/JY308 |
 |
 |
| 胶管内径mm |
公称通径mm |
d1 |
d2 |
d3 |
A |
B |
C |
O型圈
JB/ZQ4224 |
| 10 |
<70 |
6.5 |
30 |
11 |
55 |
36 |
22 |
30×31 |
| 13 |
<60 |
9.5 |
30 |
11 |
55 |
40 |
22 |
30×31 |
| 16 |
<60 |
12.5 |
30 |
11 |
55 |
40 |
22 |
30×31 |
| 19 |
<60 |
15.5 |
35 |
11 |
55 |
40 |
22 |
35×31 |
| 25 |
<50 |
21.5 |
40 |
13 |
75 |
56 |
28 |
40×31 |
| 32 |
<41 |
27.5 |
45 |
13 |
75 |
56 |
28 |
45×31 |
| 38 |
<35 |
32.5 |
55 |
18 |
100 |
73 |
36 |
55×31 |
| 51 |
<32 |
44 |
65 |
18 |
100 |
73 |
36 |
65×31 |
|
| 胶管内径mm |
公称通径mm |
工作压力(MPa) |
d |
扳手尺寸 |
| Ⅰ |
Ⅱ |
Ⅲ |
4SP |
| 6 |
6 |
20 |
25 |
40 |
100 |
R1/4 |
17 |
| 10 |
10 |
16 |
25 |
25 |
70 |
R3/8 |
22 |
| 13 |
10 |
13 |
20 |
25 |
60 |
R1/2 |
27 |
| 16 |
15 |
10 |
16 |
20 |
55 |
R3/4 |
32 |
| 19 |
20 |
10 |
16 |
20 |
46 |
R3/4 |
36 |
| 25 |
25 |
8 |
10 |
13 |
35 |
R1 |
46 |
| 32 |
32 |
7 |
10 |
10 |
32 |
R1 1/4 |
55 |
| 38 |
40 |
4 |
8 |
10 |
25 |
R1 1/2 |
60 |
| 51 |
50 |
- |
7 |
8 |
20 |
R2 |
75 |
|
| 以上各型均可加工成450或900角，如下图 |
|
